Glamox - Cameleon Mini R
Gyártó: Glamox
Termék neve: Cameleon Mini R
Felhasználás: Iroda, oktatási intézmény, üzlethelyiség, bemutatóterem, kiállítás, közösségi tér, szálloda, folyosó
LED élettartam: L70B50-L80B50 / 100000+, L90B50 / 70000 óra
Színhőmérséklet: 3000-4000 K
Sugárzási szög: 24°-38°-60°
CRI/Ra: 80+
Védelem: IP20/54, IK05
Üzemeltethetőség: 0°C - +25°C
Anyag/Optika: Edzett üveg diffúzor, műanyag csiszolt ezüst reflektor, acél / öntött alumínium ház
Opciók: Dali
Adatlap: Cameleon Mini R adatlap
Termékváltozatok
| Kód | Név | Teljesítmény (W) | Fényáram (lm) | Fényhasznosítás (lm/W) | Színhőmérséklet (K) | Hosszúság (mm) | Szélesség (mm) | Magasság (mm) |
| CML581393 | CAMELEON-R65F WH A IP20 800 HF 830 60° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML581396 | CAMELEON-R65F WH A IP54/20 800 DALI 840 60° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML581377 | CAMELEON-R65F WH A IP54/20 800 HF 830 60° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML581288 | CAMELEON-R65F WH A IP54/20 800 HF 840 60° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML581293 | CAMELEON-R65F WH A IP54/20 800 HF-E 840 60° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML572051 | CAMELEON-R65A WH IP20 800 DALI 840 60° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML572119 | CAMELEON-R65A WH IP20 800 HF 840 60° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML581385 | CAMELEON-R65F WH A IP20 800 HF-E 840 60° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML569491 | CAMELEON-R60F WH IP54/20 800 HF 840 60° | 7 | 800 | 114,29 | 4000 | 80 | 80 | 75 |
| CML570378 | CAMELEON-R65A WH IP20 800 DALI 830 38° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML581405 | CAMELEON-R65F WH A IP20 800 DALI 840 60° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML571374 | CAMELEON-R60F WH/SQ IP54/20 800 DALI 840 60° | 7 | 800 | 114,29 | 4000 | 80 | 80 | 75 |
| CML573481 | CAMELEON-R60F WH/SQ IP54/20 800 HF 840 60° | 7 | 800 | 114,29 | 4000 | 80 | 80 | 75 |
| CML569471 | CAMELEON-R65A WH IP20 800 DALI 830 24° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML569470 | CAMELEON-R65A WH IP20 800 DALI 830 60° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML571961 | CAMELEON-R65A WH IP20 800 DALI 840 24° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML571184 | CAMELEON-R65A WH IP20 800 DALI 840 38° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML573378 | CAMELEON-R65A WH IP20 800 HF 830 24° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML569478 | CAMELEON-R65A WH IP20 800 HF 830 38° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML572082 | CAMELEON-R65A WH IP20 800 HF 830 60° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML571665 | CAMELEON-R65A WH IP20 800 HF 840 24° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML571183 | CAMELEON-R65A WH IP20 800 HF 840 38° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML581372 | CAMELEON-R65F WH A IP20 800 DALI 830 38° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML581406 | CAMELEON-R65F WH A IP20 800 DALI 830 60° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML581371 | CAMELEON-R65F WH A IP20 800 DALI 840 38° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML594174 | CAMELEON-R65F WH A IP20 800 HF 830 38° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML581686 | CAMELEON-R65F WH A IP54/20 800 DALI 830 24° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML581376 | CAMELEON-R65F WH A IP54/20 800 DALI 830 38° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML581301 | CAMELEON-R65F WH A IP54/20 800 DALI 830 60° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML581687 | CAMELEON-R65F WH A IP54/20 800 DALI 840 24° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML581375 | CAMELEON-R65F WH A IP54/20 800 DALI 840 38° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML595740 | CAMELEON-R65F WH A IP54/20 800 HF 830 24° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML581439 | CAMELEON-R65F WH A IP54/20 800 HF 830 38° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML583976 | CAMELEON-R65F WH A IP54/20 800 HF 840 38° | 8 | 820 | 103 | 4000 | 80 | 80 | 75 |
| CML581390 | CAMELEON-R65F WH A IP54/20 800 HF-E 830 60° | 8 | 790 | 99 | 3000 | 80 | 80 | 75 |
| CML595793 | CAMELEON-RQ110 WH IP20 800 DALI 830 60° | 7 | 800 | 114,29 | 3000 | 120 | 120 | 120 |
| CML595794 | CAMELEON-RQ110 WH IP20 800 DALI 840 60° | 7 | 800 | 114,29 | 4000 | 120 | 120 | 120 |
| CML595780 | CAMELEON-RQ110 WH IP20 800 HF-E 830 38° | 7 | 800 | 114,29 | 3000 | 120 | 120 | 120 |
